Hitting difficult targets
In the 1990s, high-throughput screening (HTS) was touted as the future of hit generation. Through the decade, combinatorial chemistry, automation and the exploration of physical chemical space, allied to a focus on in vitro biology, led to the rise of a more probabilistic approach, and HTS became routine.
And whilst the biggest source of molecules entering clinical trials remains HTS, followed by knowledge-based approaches, it’s fair to say that HTS has not had the predicted impact. There has been a steady flow of compounds from screens that will never make drugs because their properties are sub-optimal, alongside a recognition that the targets being addressed today are more difficult to prosecute than those of two decades ago.
For these more challenging targets, other approaches are beginning to show benefit, and more knowledge-based approaches are becoming of increasing interest. So, while HTS remains a great tool, the number of other tools available to find chemical matter is growing.
Beyond HTS
Whilst HTS allows the investigation of perhaps a million or so compounds, more expansive screening has been enabled through the evolution of DNA-encoded library screening, or DEL. The ability to screen several billions of compounds in a single tube against drug targets of interest is a compelling proposition, but it does raise its own challenges – particularly around the nature of the hits.
These hits can be difficult to translate into leads with acceptable properties. But where DEL screens do particularly add value is for complex targets with unclear biological readouts or where there are no pre-existing ligands – areas where the more immediately tractable approaches of HTS and knowledge-based hit finding are perhaps not applicable.
Whilst we often focus upon the molecular properties of our hits, it’s worth noting that moving outside traditional HTS hits and Ro5 space does not specifically preclude drug-likeness, as has been demonstrated by the increase of interest, and clinical progression, of natural product-like macrocycles as valuable hit matter against challenging targets, including protein-protein interactions. These approaches have also been further expanded through genetic techniques, using phage display to generate vast, diverse libraries of cyclic peptides which can be used to rapidly generate hits and probes against emerging biological targets. But again, like DEL hits, these hits may require significant optimisation to convert them from biologically interesting probe molecules to ones useful as human medicines.
At the other end of the size spectrum from macrocyclic compounds and DEL hits, fragments can be very useful in determining whether a protein has druggable binding pockets. Hits will need to be evolved into something more drug-like, and this process is significantly enhanced with the knowledge of structural information about the fragment-target binding to direct the medicinal chemist’s thinking. Fragment screens have the advantage that fewer molecules need to be screened to encompass similar diversity, and may help to identify dynamic or transient pockets that are not captured in more traditional structure-based methods.
Indeed, cryptic pockets that only appear when a drug binds to them are of increasing interest, but their dynamic nature means that currently available technologies are less successful in identifying hits. Some companies claim to be able to follow protein conformational changes computationally and identify novel binding regions, with chemoinformatics and ligand-based screening, for example, now being joined by AI/ML techniques that might be able to provide more dynamic structural information. While AI companies have made big investments in the area, there is still little evidence of impact as yet in the public domain.
Recently, these computational techniques have returned to the fore, and virtual screening is being relied upon more and more, particularly with access to ultra-large virtual libraries. Is the big promise for the next 20 years the ability to use artificial intelligence (AI) and machine learning (ML) to query these ultra-large virtual libraries? A common tactic today is to use ligand-based 3D shape matching with a virtual library, such as Enamine’s Real database, which now includes nearly two billion molecules with potentially drug-like properties. If the active site (or other binding pocket) can be identified, it should be possible to use computational chemistry in a more directed way to find a high-quality hit. This, however, remains something of an art and is not a guarantee of success.
And even though AI/ML specialists can now screen ultra-large libraries very quickly, many approaches focus primarily upon potency, and optimising drug-like properties remains a challenge for many systems. While a low-affinity ligand can often be evolved to a nanomolar one, far less attention is paid to druggability and pharmacokinetic profiles at this early stage. The ability to rapidly assess hit matter through commercial “analogue by catalogue”, discarding poor quality hits and prioritising promising ones, can significantly accelerate progress. There is now much more of a focus among library companies on providing molecules that are evolvable, and some, like Enamine, have materials on the shelf ready to make and evolve focussed compound libraries quickly. However, large physical libraries rarely exist these days, away from the large cocktails of compounds in DNA-encoded and phage display libraries.
Designing better libraries
Regardless of hit finding technique, one concern with existing libraries is that if they are all based on precedented chemistry, how useful will they be for unprecedented targets? The shape of a new binding pocket may be unknown, yet little attention is paid to shape diversity within a typical screening collection. Diversity in the library, whether real or virtual, is key. An example of a modern approach to library creation is Sygnature’s own internal virtual library of about 17 million compounds; while relatively small, it is based on diverse and proprietary drug-like scaffolds, and three-dimensional shape diversity. These are increasingly being recognized as key factors in library creation. Similarly, Sygnature’s fragment library is designed to be diverse, with useful chemical functionality on the fragments to make the hit-to-lead process faster and more efficient.
And that efficiency of prosecution is of critical importance. Regardless of how a hit is generated, the identification of those with properties suitable for optimisation, and ultimately development, remains challenging, and any screening approach might ultimately only lead to probe molecules that cannot be prosecuted into drugs.
In some respects, finding a hit is the easy part. The conversion of that hit into a molecule with all the requisite properties to become a drug remains the greater challenge. If a screen provides a hit set of, say, 20 compounds, each of which has two or three vectors that requires exploration, that’s a significant synthetic task to fully explore, unless they can be further prioritised in some way. And this consideration of the underlying library design, and its future “workability” for expedient exploitation into drug candidate molecules, is of critical importance to success. Ideally, the library components will sit within larger, accessible commercial space so that rapid hit follow-up can be undertaken rapidly and effectively, with access to both commercially available elaborated derivatives, bulk scaffolds and intermediates for internal synthetic efforts.
Most importantly, the nature of the target should always dictate the strategy applied to lead finding. The ability to access different compounds and novel chemical space is already having an impact, whether this is through more traditional HTS, virtually, or through the creation of large macrocycles. As an overall process, it is still somewhat hit and miss, but with an educated and informed choice of hit finding, and perhaps a little bit of luck, hits (and eventually drugs) for these emerging, challenging targets can indeed be delivered.
